3032L

share it:

· Description: 30 A, 120V, Double-Pole Switch, Illuminated - Load ON (Pilot Light) · Color: White, Ivory · Rating: 30A, 120VAC · HP Rating: 2HP-120V · Grounding: Grounding · Termination: Side · Dielectric Voltage: Withstands 1500V for 1 minute · Actuator Material: Thermoplastic PC · Body Material: Thermoplastic Nylon

FEATURES CODE COMPLIANCE MATERIAL CHARACTERISTICS

· Extra-long, through-body strap eliminates floating installations and imperfect applications
· Heavy-duty impact-resistant thermoplastic construction for long service life
· Back and side-wiring terminals accept both solid and stranded wire to ease installation
· Smooth, quiet paddle and toggle action
· Narrow back body leaves more room for wires in the box
· Tri-Drive ground, terminal and mounting screws ease installation
· Terminal screw backed out ready for wiring
· Limited Two-Year Warranty

· UL Listed 20, UL file #E310558
· ROHS comply

· Environmental: Flammability, UL-94, Rated V0
· Operating Temperature: -40° F to 149° F (-40° C to 65° C)
